Ip Network Camera
| Payment Terms: | T/T,L/C,WU;paypal |
| Place of Origin: | Guangdong, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
1. 420tvl SONY 1/3 CCD sensor
2. 20M IR distance
3. Temperature:-10~50℃
4. Maximum frame rate:25fps
5.Provide DDNS for free, like demo.
wifi ourdoor IP Network Camera
Model: ZS-M622
Model: ZS-M622
| Catalogue | Type | Parameters |
| Features | View by phone | Support monitoring via mobile devices on line(such as iOS, Android OS,Symbian OS,WindowsPhone7) |
| Mobile Platform | No need to install sof tware, Multi-screen monitoring and managing by mobile phone,alarming,viewing. | |
| View on PC | Internet Explorer 6.0 or higher version,firefox,chrome | |
| Super Client | 1,4,9,16,25,36, 64,81-channel , no user limited, centralized monitor, remote record and playback , Skype message alarm, skype telephone alarm | |
| System | Operation system | Embedded Linux OS |
| System security | Supports three-level account, password, user multi-level authority management | |
| DDNS | Provide DDNS for free, like demo.gocam.so | |
| Collection | Image sensor | 1/3 420tvl SONY CCD sensor |
| SNR | ≥48dB | |
| Minimum Illumination | 0.1Lux | |
| 3A | Auto White Balance, Auto Exposure,Automatic Gain | |
| Lens | Standard:6mm | |
| Video | Compression Format | H.264 main prof ile level 3/Motion-JPEG Dual-stream |
| Resolution of Main Stream | D1(704×576)/CIF(352×288)/QCIF(176×144 ) | |
| Resolution of Second Stream | CIF, QCIF can be selected | |
| Maximum frame rate | 25fps | |
| Bit Rate | 32Kbps~4Mbps can be selected | |
| Adjustment | light intensity,contrast ratio,saturation level are adjustable. | |
| Nightvision | Effects | 30 Φ5 LEDs IR Distance:20m |
| Audio | Encode formats | G.711/G.726 |
| Input | one channel linear input /Microphone Input,normal connector of 3.5mm | |
| Output | one channel linear output,normal connector of 3.5mm | |
| Network | Socket | RJ-45 10/100Mb self-adaptable Ethernet slot |
| Protocol | TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,PPPoE, etc | |
| WIFI | WIFI 802.11 b/g/n | |
| Visitors Online | Support 10 visitors viewing on line at the same time | |
| P/T | Control Method | 1 way RS485 |
| Protocol | PELCO-D/PELCO-P agreement,Baud rate:2400-9600, Address:0-255 | |
| Alarm | Alarm Detection | Support motion detecting for 4 regions / 1 way input triggered |
| Alarm action | 1 way output/E-mail pictures /upload video by FTP/messages alarm(coordinate to server) | |
| Physical index | Power | DC 12V |
| Comsumption | <6W | |
| Temperature | -10~50℃ | |
| Humidity | 10%~85% | |
| Weight | Net:900g Gross:1228g (Note: in kind prevail) | |
| Body Size | 185 x 75 x53mm (L*W*H) | |
| Package size | 240 x179 x97mm (L*W*H) | |
| Certification | CE, FCC, ROHS | |
